Where Comfort and Convenience Meet
The Node is for riders who want it all: the convenience of a folding bike plus the comfort of a big sturdy city bike. The Node rolls on full-size wheels and rides like a Dutch city bike—but folds down small in seconds for easy storage, transport, and security. At the intersection of folding and full-size, the Node stands ready for service.
Compact Folding Convenience
Despite its big bike bona fides, the Node folds down small in about 10 seconds. The Node’s folded size is compact enough to carry it onto the subway, stick it in the trunk of your car, or stash it under your desk at work. With more places to go and fewer opportunities for theft, folding means freedom.
OCL+™ FRAME JOINT
ROBUST FOLDING TECHNOLOGY
A heavy-duty update to our iconic OCL frame hinge, the OCL+ is built to exceed ISO 4210 and EN 15194 testing requirements. Leveraging the hinge design of the long-tail Tern Cargo Node, the OCL+ features a single-shaft design, advanced welding techniques, and robust gussets, so it stays stiff and strong during even the fastest commutes.
PHYSIS™ 3D HANDLEPOST
THE NEW BENCHMARK
Five patented technologies and unique manufacturing technology add up to the strongest, stiffest folding handlepost available. The Physis uses a special manufacturing process called 3D forging, which forms the post from a single piece of aluminum, eliminating all welds.
ANDROS™ STEM
ADJUST TO FIT
The Andros is our patented adjustable stem that lets you set your handlebars where you want—no tools, no fuss. In just seconds, you can set your riding position to long and low in a tough headwind, or upright and comfy for riding around town. You decide how you want to ride and the Andros makes your bike fit.
Swept-Back Handlebars
When you ride around the city, you want to take it all in. Our swept-back handlebars let you sit comfortably upright so you can see everything that goes by. And a more natural grip position is extra kind on your wrists.
Velo Ergonomic LockOn Grips
ErgoLock grips are nice and wide for excellent palm support so your hands can relax during the ride. They also lock in place on the handlebars so they’re always in the correct position, unlike non-locking grips which tend to rotate out of position.
Freelance™ Fenders
The Freelance Fenders have a hidden rear stay design to keep the design of the bike clean and uncluttered. But good looks wouldn’t mean much unless they did a great job of keeping road spray off you. And that’s just what they do.
Specifications
SPEEDS: | 1 x 8 |
WEIGHT: | 13.3 kg (29.3 lb) |
GEAR INCHES: | 33″ – 96″ (2.64 – 7.67 m) |
FOLDING SIZE: | 39 × 86 × 84 cm (15.4 × 33.9 × 33.1 in) |
FOLDING TIME: | 10 sec |
FRAME SIZES: | One size |
DISTANCE: SEATPOST TO HANDLEBAR: | 67 – 73 cm (26.4 – 28.7 in) |
DISTANCE: SADDLE TO PEDAL: | 79.5 – 105 cm (31.3 – 41.3 in) |
SUGGESTED RIDER HEIGHT: | 148 – 195 cm (58.3 – 76.8 in) |
MAX GROSS VEHICLE WEIGHT: | 120 kg (264.6 lb) |
MAX RIDER WEIGHT: | 105 kg (231.5 lb) |
FRAME: | Tern Node, aluminum, OCL+ joint, 2 patented technologies |
FORK: | Integrated, hi-tensile steel |
HANDLEPOST: | Tern Physis 3D (G2), 3D forged, 5 patented technologies, 12°, 290 mm |
STEM: | Tern Andros, adjustable, forged construction, patented technology |
HEADSET: | Flux, cartridge bearings, Physis integrated |
HANDLEBAR: | Tern Sweep, 6061-AL, Tern Andros butted |
GRIPS/BAR TAPE: | Velo ergonomic, lock-on |
SADDLE: | BioLogic Como DLX |
SEATPOST: | SuperOversize, 6061-AL, micro-adjust clamp |
SEATPOST CLAMP: | SuperOverize, 6061-AL |
FRONT BRAKE: | V, aluminum, linear spring |
REAR BRAKE: | V, aluminum, linear spring |
BRAKE LEVERS: | V, aluminum bracket/lever |
BRAKE CABLE & HOUSING: | Anti-compression housing, slick cables |
FRONT HUB: | Aluminum; Opt: Shimano 1.5W dynamo |
REAR HUB: | Formula, 8 spd cassette, QR |
SPOKES AND NIPPLES: | Sapim Leader, stainless steel |
RIMS: | Doublewall aluminum |
TIRES: | Schwalbe Big Apple, 50-507, puncture protection, Reflex |
SHIFTER(S): | Shimano,1 x 8 spd, trigger |
REAR DERAILLEUR: | Shimano Claris |
CRANKSET: | Cold-forged 6061 aluminum crank arms, hand-polished |
CASSETTE/FREEWHEEL: | Shimano, 11-30T, 8 spd |
BOTTOM BRACKET: | Cartridge, sealed bearings |
CHAIN: | 8 spd |
PEDALS: | Folding, alloy body |
SHIFTER CABLE & HOUSING: | SP |
BELL: | Aluminum |
KICKSTAND: | Deluxe center mount |
CLIP SYSTEM: | Magnetix 2.0 |
LUGGAGE SOCKET: | Yes |
FENDERS: | Freelance, stainless hardware |
RACK(S): | Tern Freight Rack; Max load weight: 25 kg (55 lb) |
